欢迎访问泰克产品支持
虽然我们很愿意与您全天“讨论技术问题”，但我们知道您时间宝贵。因此，我们简化了流程，让您可以轻松下载所有当前产品以及许多停产产品的手册、产品技术资料和软件。只需告诉我们您使用的是哪种产品，我们就会向您显示所有相关信息。
您选择的产品型号是已停产产品。提供以下支持信息。
-
产品技术资料 文献编号： 发布日期 M-PHY接收器解决方案产品技术资料
GRL’s MIPI MPhy Receiver Calibration and Test Application Software for the Tektronix BERTScope™ BSA(GRL-MIPI-MPHY-RX) provides an automated, simple, and efficient way to test MIPI MPhy Receiver to the Jitter Tolerance and other test requirements of …Bit Error Rate Tester
The BERTScope Bit Error Rate Tester Series provides a new approach to signal integrity measurements of serial data systems. Perform bit error rate detection more quickly, accurately, and thoroughly by bridging eye diagram analysis with BER pattern …65W-25444-15
-
手册 手册类型 部件号： 发布日期 Tektronix BERTScope
BSA & BA Remote Control Guide Programmer Manual程序员 077069605 Tektronix BERTScope
Bit Error Ratio Analyzers & Pattern Generators Quick Start User Manual主要用户 071286904 Tektronix BERTScope
BSAPCI3 Instructions用户 071304600 Tektronix BERTScope BSA Series
Declassification and Security Instructions解密 077079100 ITSRACK
Rackmount Instructions用户 071305100 Tektronix BERTScope
BSAITS125 Declassification & Securities Instructions解密 077069500 BERTScope Analyzers
BERTScope Bitalyzer Remote Control Guide Programmer Manual程序员 077067700 BERTScope Analyzers
BERTScope Bitalyzer Remote Control Guide Programmer Manual程序员 077055400 BERTScope Analyzers
BERTScope Bit Error Ratio Analyzer Instructions Quick Start User Manual用户 077055200
-
技术文档 文档类型 发布日期 高速接口标准
本电子指引将帮助您进一步了解PCIe 4.0、SAS、SuperSpeed USB和DDR4标准测试时面临的设计挑战。在这本电子指引中，您还将快速获得许多技术资源，帮助您了解设计挑战，根据测试需求选择适当的解决方案。操作指南 USB 3.1接收机一致性测试
In this application note, all aspects of USB 3.1 receiver testing are covered, including stressed eye calibration and jitter tolerance testing with measured device margin.应用指南 消除BER和眼图之间的空白 — BER廓线教程
BER廓线测量 - 这是什么，是怎样构建的，为什么为查看千兆位速度的参数性能提供了重要方式。应用指南 25 Gb/s信令测量方法
本应用指南介绍了100 G系统中25+ Gb/s信令发射机和接收机检定和一致性测试的测量方法，重点是示波器测量，部分涉及BERT。应用指南 BSA 系列BERTScopeTM 误码率分析仪速查表
本文档描述了BSA 系列BERTScopeTM 误码率分析仪的主要性能和订购信息。速查资料 100 Gb/s通信系统物理层测试
本应用指南介绍了怎样准备100G标准一致性测量，包括IEEE802.3ba，以及帮助您诊断不满足标准的元器件和系统及测量性能余量的多项测试。应用指南 时钟恢复对测试测量的影响
随着时钟恢复在越来越多的系统和测试设置中普及，必须考虑其对测量的影响。许多外部影响可能会破坏数据及时钟输入方式之间的关系。通过了解双方之间的关系，可以获得更加实用、更加准确的测量结果。应用指南 >1UI 抖动压力校准
测量信号上存在的抖动数量在概念上相对简明，但在这个数量超过一个位周期(1个单位间隔或UI)时则会变得比较困难。这给USB 3.0之类的标准带来了实际影响，其中要求以500 kHz的正弦曲线抖动，在2 UI的测试设备上进行校准。本指南介绍了在BERTScope上使用码型和触发，实现这些校准。应用指南 检定16G光纤通道速率的SFP+收发机
研究根据16G光纤通道标准测试SFP+收发机所需的测量，同时覆盖多模850 nm接口和单模1310 nm接口。其中包括一个测试和检定实例，采用单模1310 nm激光器SFP+收发机及14.025 Gb/s的16G线速，同时采用一流的测试设备。入门指南 PCI Express®发射机PLL测试 — 不同方法对比
根据使用的测试仪器类型，可以通过多种方法测量PLL环路响应。正如预期的那样，各种方法在测试精度、测试速度(吞吐量)、易用性、设置简便性和购买费用上各有优势和劣势。此外，某些方法存在局限性，不能广泛用于所有类型的PLL。尽管所有方法都可以测试是否满足规范要求，但某些方法为时钟设计人员优化设计提供了额外的实用信息。入门指南 受压眼图：“知道你实际测试的是什么”
基于BER的测量可以更好地了解压力眼图张开，支持测试时接收机预计将工作的深入BER电平。入门指南 时钟恢复入门手册，第二部分
从实践角度考察时钟恢复，重点介绍其对测量的影响，第二部分。入门指南 时钟恢复入门手册，第一部分
从实践角度考察时钟恢复，重点介绍其对测量的影响，第一部分。入门指南 双Dirac+示波器直方图和BERTScan测量
本入门手册讨论了双Dirac与使用采样示波器和基于BER的仪器可以进行的实际测量的关系。入门指南 使用基于BER的抖动测量评估压力成分
本入门手册介绍可以怎样使用基于BER的抖动峰值测量自检抖动测量，以及怎样使用不会导致码型相关影响的码型简化抖动测量，最后本文说明了不同的压力损伤对总抖动(TJ)有哪些影响。入门指南 BERTScope®误码测试仪抖动分离及定位解密
以全新方式钻研抖动问题，如考察数据码型每个边沿上的随机抖动，分隔发射机预加重导致的抖动，在PRBS-31之类的长码型上执行抖动分解。应用指南 使用BERTScope®误码率测试比较抖动
比较DCD和F/2抖动。应用指南 使用BERTScope®误码率测试仪进行六希格玛模板测试
六希格玛是一种模板测试形式，在模板测试深度指标对通过/失败测试非常重要时，提供了关键信息，它可以更深入地评估高速信令标准，明显更全面地了解器件性能。应用指南 Stressed Eye Primer
Figure 1. Conceptual picture of an ideal receiver. Figure 2. Simplified Receiver Block Diagram. Abstract Many high-speed serial …入门指南 Exploring Power Supply Voltage Sensitivity in an IC with a BERTScope® Bit Error Rate Tester
Eye diagrams alone may not be as effective in showing major system issues and should be coupled with BER-based measurements for deeper insight and problem resolution.应用指南 Exploring Power Supply Voltage Sensitivity in an IC with a BERTScope® Bit Error Rate Tester
Eye diagrams alone may not be as effective in showing major system issues and should be coupled with BER-based measurements for deeper insight and problem resolution.应用指南 D.C. Blocks, a Trap for the Unwary When Using Long Patterns
It is obvious to focus on ensuring that the upper frequency of the range is adequate to pass the desired data signal; while it is less obvious to worry about the low end frequency specification, this application note discusses that it can be equally …应用指南 Signal Integrity of Reference Clock Bleed-Through in an IC
This application note examines some signal integrity examples related to AMB testing, but also with wider applicability. Clock bleed-through is examined, as well as the effect of a lowered supply voltage on error performance.应用指南
-
软件 文档类型 部件号： 发布日期 Tektronix Receiver Test Application Software for USB3.1 Gen1 and Gen2 - V2.3.0
USB 3.1 Gen1 and Gen2: Testing is described in the USB-IF Compliance Test Specification (CTS) document. Receiver testing is accomplished by connecting the output of a BERT pattern generator as an input to the DUT, through a specialized set of …应用 066195002 BERTScope Application Software, V11.02.1903
BERTScope(R) Analyzers are designed for applications from 500 Mb/s to 28.6 Gb/s. They are the industry`s first multi-Gb/s instruments that combine the eye diagram analysis capabilities of high-bandwidth sampling oscilloscopes together with BER …应用 066165804 BSAUSB31 USB 3.1 Receiver Test Application Software, V1.1.1907
The BERTScope USB 3.1 Receiver Test Automation Software runs on a BERTScope or PC, and connects to the BERTScope, DPP, CR, and Instrument Switch test equipment via LAN. It uses remote control automation protocols to fully automate USB 3.1 calibration …应用 066171100 BERTSCOPE APPLICATION SOFTWARE, V11.02.1886
BERTScope(R) Analyzers are designed for applications from 500 Mb/s to 28.6 Gb/s. They are the industry`s first multi-Gb/s instruments that combine the eye diagram analysis capabilities of high-bandwidth sampling oscilloscopes together with BER …应用 066165802 BSAPCI3 PCIe 3.0 Receiver Test Application Software, V1.1.1449
The PCIe 3.0 Receiver Test Automation Software (BSAPCI3) runs on a BERTScope or peripheral PC, and connects to a BERTScope and DPP (Digital PreEmphasis Processor) test equipment via LAN. It uses remote control automation protocols to fully automate …应用 066156501 BERTScope Software Release, V 10.15.1284
BERTScope(R) Analyzers are designed for applications from 500 Mb/s to 28.6 Gb/s. They are the industry`s first multi-Gb/s instruments that combine the eye diagram analysis capabilities of high-bandwidth sampling oscilloscopes together with BER …固件 066148402 BERTScope Software Release
BERTScope(R) Analyzers are designed for applications from 500 Mb/s to 26 Gb/s. They are the industry`s first multi-Gb/s instruments that combine the eye diagram analysis capabilities of high-bandwidth sampling oscilloscopes together with BER pattern …应用 066123808 BERTScope Driver for LabVIEW V1.0.2
BERTScope? and BERTScope? S Driver for LabVIEW Version 1.0.2 Release Date: June 1, 2006驱动程序 066130500 BERTScope Software Release V 10.11.1006
BERTScope(R) Analyzers are designed for applications from 500 Mb/s to 26 Gb/s. They are the industry's first multi-Gb/s instruments that combine the eye diagram analysis capabilities of high-bandwidth sampling oscilloscopes together with BER pattern …固件 066123802 Bertscope SATA Support files V1.0
The compressed file has the BERTScope User patterns and JTOL files for the Bertscope SATA application.波形 066124800 Bertscope USB 3.0 Support files V1.0
The compressed file has the User patterns, Mask, JTOL and Configuration files for the Bertscope USB 3.0 application.波形 066124700 Bertscope PCI Express Support Files V 1.0
The compressed file has BERTScope User patterns, Mask Files and Jitter Tolerance files for the Bertscope PCI Express Application.波形 066124600 Bertscope SAS Support files V1.0
The compressed file has the BERTScope User patterns and Jitter Tolerance files for the Bertscope SAS application.应用 066124900 Bertscope Software Support - Jitter Tolerance Template files V1.0
BERTScope Template files to be used with the Jitter Tolerance applications.波形 066125000
-
常见问题 常见问题 ID Can Microsoft Remote Desktop be used with Windows based oscilloscopes?
Yes, the Remote Desktop feature of the Professional Editions of Windows can be used on Tektronix DPO/MSO/CSA Series Oscilloscopes running Windows XP or later operating systems. In order to use the Remote Desktop feature of Windows, you will need to …61606 I have lost or damaged one of the front panel signal connectors on my Tektronix BERT scope. How do I obtain a replacement connector?
A replacement connector is Tektronix p/n 131906200. These connectors are designed to be easily replaceable as they unscrew from the permant front panel input connector. When damaged, you remove the damaged connector and replace with a new connector …64646 I want to know how to view the .ram user pattern files on the BERT scopes. I used to be able to view them but cannot locate the process anymore. I would like to view them in hex format. If I recall correctly, the .RAM format includes repeats for sections of the data, and isn't directly readable.
For viewing of RAM files, use the Editor view. Within the Editor view, press File, Open, Raw RAM Memory File.64856 How do I use TekExpress to perform a USB 3.0 Device Transmitter Test?
USB 3 Tx Testing ScriptHello and welcome to Tektronix! Today I’m going to walk through a USB 3 Device Transmitter Test using TekExpress.A USB 3 Transmitter test consists of acquiring the signal from a USB 3 Device and running it through various tests …69376
