Real-Time Spectrum Analyzer Software Options

Measurement Software Options for RSA3408A • RSA3303A • RSA3308A

泰克对于本技术资料上的产品不再有售。
查看 Tektronix Encore 了解翻新测试设备。
查看这些产品的支持和保修状态。

Measurement Software Options for RSA3408A • RSA3303A • RSA3308A

Features & Benefits

Trigger

Tektronix Exclusive Frequency Mask Trigger Makes Event-based Capture of Transient RF Signals Easy by Triggering on Any Change in the Frequency Domain

Capture

All Input Signals up to 36 MHz*¹ Spans are Seamlessly Captured Into Memory
Long Record Length Enables Complete Analysis Over Time Without Making Multiple Acquisitions
Interfaces with TekConnect® Probes for RF and Baseband Probing

Analyze

Analyze Frequency, Amplitude, and Modulation Over Time
Multi-domain Analysis Enables Fast, Complete Signal Analysis in Frequency, Time, Code, and Modulation Domains
General Purpose Digital Modulation Analysis
802.11a/b/g/n Measurement Suite
Codogram Provides a Simple, Graphical Means of Analyzing Individual Code Powers versus Time
Key Signaling Analysis Over Air Interface Enables Checking Interaction between Base station and UE
Signal Source Analysis Simplifies Phase Noise, Jitter, and Frequency Settling Measurements

Applications

W-CDMA
HSUPA
HSDPA
GSM/EDGE
CDMA2000 1x
CDMA2000 1xEV-DO
TD-SCDMA
RFID
Phase Noise
Jitter
IEEE 802.11 a/b/g/n WLAN
IEEE 802.15.4 OQPSK (Zigbee)
P25 (C4FM signal analysis )
Digital Modulation Analysis

*¹ RSA3408A: 36 MHz RF, 40 MHz Baseband; RSA3300A: 15 MHz RF, 20 MHz Baseband.

Trigger, Capture, Analyze

See frequency, amplitude and modulation change over time. With only a single acquisition, Real-Time Spectrum Analyzers (RTSA) capture a continuous time record of changing RF events and enable time-correlated analysis in the Frequency, Time, and Modulation domains. You get the functionality of a vector signal analyzer, a wide band spectrum analyzer, plus the unique trigger-capture-analyze capability of RTSA — in one package. Optional application-focused software allows you to tailor the advanced characterization and troubleshooting tools of the RTSA to meet the needs of your specific application.

	RSA3303/8A	RSA3408A
General Purpose Modulation	Opt. 21	Opt. 21
W-CDMA Uplink		Opt. 23
GSM/EDGE		Opt. 24
CDMA 1X Forward/Reverse Link		Opt. 25
1X EVDO Forward/Reverse Link		Opt. 26
3GPP Release 5 Downlink (HSDPA)		Opt. 27
3GPP Release 6 (HSUPA)*²		Opt. 40
TD-SCDMA		Opt. 28
WLAN 802.11a/b/g/n		Opt. 29

*² For 3GPP Release 6 (HSUPA) analysis, opt 23, 27 are required in addition to opt 40.

Characteristics

Opt. 21 – Advanced Measurement Suite

Modulation Format - BPSK, QPSK, OQPSK, π/4 - DQPSK, 8PSK, 16QAM, 32QAM, 64QAM, 128QAM, 256QAM, GMSK, GFSK, ASK, FSK, DSB-ASK, OOK, PR-ASK, SSB-ASK, Subcarrier OOK, Subcarrier BPSK, C4FM (Fixed symbol rate).

Maximum Symbol Rate -

RSA3408A: 51.2 MS/s

Parameter Presets - PDC, PHS, NADC, TETRA, GSM, CDPD, Bluetooth, IEEE 802.15.4 OQPSK (Zigbee), P25.

Vector Diagram Display Format - Symbol Locus Display, Frequency Error and Origin Offset Measurement.

Constellation Diagram Display Format - Symbol Display, Frequency Error and Origin Offset Measurement.

Eye Diagram Display Format - I/Q/Trellis Display (1 to 16 symbols).

Error Vector Diagram Display Format - EVM, Magnitude Error, Phase Error, Waveform Quality (ρ), Frequency Error, and Origin Offset Measurement.

Coding Format - NRZ-L (8 periods), NRZ-L (4 periods), NRZ-L (2 periods), PWM, Bit Cell, Miller, Modified Miller, Miller (M_2), Miller (M_4), Miller (M_8), Manchester, NRZ.

Symbol Table Display Format - Binary, Octal, Hexadecimal.

Signal Source Analysis - Phase Noise, Jitter, and Automated Frequency Settling Measurement.

RFID Standards - ISO/IEC 18000 Part 4 Mode 1.

ISO/IEC 18000 Part 6 Type A, B, C.

ISO/IEC 18092

ISO/IEC 14443 Part 2 Type A, B

EPC Global Generation 1 Class 0, Class 1

Digital Demodulation

GMSK (1 MHz Span) - EVM ≤1.8%, Magnitude Error ≤1.2%, Phase Error ≤1.0°

64QAM, 5.3 MS/s 1 GHz Carrier (15 MHz Span) - EVM ≤2.5% (typical).

QPSK, 3.84 MS/s 2 GHz Carrier (15 MHz Span) - EVM ≤2.5% (typical).

Characteristics	RSA3408A
QPSK EVM CF = 2 GHz (typical value)	0.5% (at 100 kS/s) 0.5% (at 1 MS/s) 0.6% (at 4 MS/s) 0.9% (at 10 MS/s)

Characteristics

RSA3408A

QPSK EVM CF = 2 GHz (typical value)

0.5% (at 100 kS/s)

0.5% (at 1 MS/s)

0.6% (at 4 MS/s)

0.9% (at 10 MS/s)

Signal Source Analysis

STABILITY

RSA3408A

Noise Sidebands, dBc/Hz

Offset	At 1 GHz CF		At 2 GHz CF		At 6 GHz CF
	Spec	Typical	Spec	Typical	Spec	Typical
1 kHz	-105	-107	-103	-105	-97	-99
10 kHz	-110	-112	-109	-111	-106	-108
20 kHz	-110	-112	-109	-111	-106	-108
30 kHz	-110	-112	-109	-111	-106	-108
100 kHz	-112	-115	-112	-115	-111	-113
1 MHz	-132	-135	-132	-135	-132	-134
5 MHz	-138	-140	-138	-140	-137	-139
7 MHz	-138	-140	-138	-140	-137	-139
10 MHz	-138	-140	-138	-140	-137	-139

STABILITY

RSA3308A/3303A

Noise Sidebands, dBc/Hz

Offset	At 1 GHz CF		At 2 GHz CF		At 6 GHz CF
	Spec	Typical	Spec	Typical	Spec	Typical
1 kHz	-100	-107	-96	-99	-87	-90
10 kHz	-105	-112	-104	-107	-104	-107
20 kHz	-105	-112	-105	-108	-105	-108
30 kHz	-105	-112	-105	-108	-105	-108
100 kHz	-112	-115	-112	-115	-112	-115
1 MHz	-132	-135	-132	-135	-128	-131
5 MHz	-135	-140	-135	-138	-130	-133
7 MHz	-135	-140	-135	-138	-130	-133

Frequency Settling Time

RSA3408A (typical)

Input Power - –5 dBm

RF Attenuator - 0 dB

Smoothing Factor - 1

Span - ≥10 MHz

Input Frequency - 100 MHz – 101 MHz

Frequency Settling Threshold - 100 kHz

Span - 100 kHz

Input Frequency - 10 MHz – 10.01 MHz

Frequency Settling Threshold - 1 kHz

Span (Hz)	Error Frequency Settling Time	Error Frequency Settling Time From Trigger
36 MHz	60 ns	100 ns
10 MHz	240 ns	240 ns
100 KHz	19 μs	19 μs

RSA3300A Series (typical)

Input Power - –5 dBm

RF Attenuator - 0 dB

Smoothing Factor - 1

Span - ≥10 MHz

Input Frequency - 100 MHz – 101 MHz

Frequency Settling Threshold - 100 KHz

Span - 100 kHz

Input Frequency - 10 MHz – 10.01 MHz

Frequency Settling Threshold - 1 kHz

Span (Hz)	Error Frequency Settling Time (S)	Error Frequency Settling Time From Trigger (S)
15 MHz	160 ns	40 ns
10 MHz	240 ns	80 ns
100 kHz	19 μs	13 μs

Opt. 23 - W-CDMA Uplink Analysis

Perform key measurements for 3GPP TS34.121 including PRACH analysis capability.

Supports the following measurements - Constellation, EVM, Eye Diagram, Symbol Table, CDP Spectrogram, CDP vs. Short Code, CDP vs. Symbol, CDP vs. Time Slot, Symbol Constellation, Symbol EVM, Symbol Eye Diagram.

Supports W-CDMA uplink signals - DPDCH 9 Dedicated Physical Data Channel/DPCCH (Dedicated Physical Control Channel), PRACH (Physical Random Access Data Channel), PCPCH (Physical Common Packet Channel).

Opt. 24 - GSM/EDGE Analysis Software

Perform key measurements for ETSI TS 100 910 and 3GPP TS45.005.

Burst Type: Normal

Characteristics	Description
Modulation accuracy measurement
Mean power measurement
Power versus time measurement
Modulation spectrum measurement
Switching spectrum measurement
Carrier power range	–30 to +30 dBm
Phase error measurement accuracy for GMSK modulation (typical)	≤0.8° (RMS) ≤1.8° (Peak)
Phase error resolution	0.01°
EVM measurement accuracy for 8-PSK modulation (typical)	≤0.9% (RMS)
EVM resolution	0.01%
Time resolution	0.15625 μs at 5 MHz span
Burst count	1000 maximum
RF input range	-50 dBm to +30 dBm
Absolute power measurement accuracy for GSM900 at 20 °C to 30 °C, excluding mismatch error (typical)	±0.5 dB Signal frequency: 880 MHz – 960 MHz, Signal power: +10 dBm to –30 dBm, RF attenuator: 0 dB – 20 dB, after auto level is performed at 5 MHz span
Absolute power measurement accuracy for DCS1800/PCS1900 at 20 °C to 30 °C, excluding mismatch error (typical)	±0.6 dB Signal frequency: 1710 MHz – 1990 MHz, Signal power: +10 dBm to –30 dBm, RF attenuator: 0 dB to 20 dB, after auto level is performed at 5 MHz span
Resolution	0.01 dB
Burst count	1000 maximum
RF input range	–50 dBm to +30 dBm
Power ramp relative accuracy (typical)	±0.2 dB at 0 dBfs to –40 dBfs
Time resolution (typical)	0.15625 μs at 5 MHz span
Marker amplitude resolution	0.001 dB
Burst count	1000 maximum
Carrier power range	–5 dBm to +30 dBm
Dynamic range for GMSK modulation (typical)	82 dB at 600 kHz offset (30 kHz RBW) 86 dB at 1.2 MHz offset (30 kHz RBW) 83 dB at 1.8 MHz offset (100 kHz RBW) 85 dB at 6 MHz offset (100 kHz RBW)
Dynamic range for 8-PSK modulation (typical)	82 dB at 600 kHz offset (30 kHz RBW) 85 dB at 1.2 MHz offset (30 kHz RBW) 83 dB at 1.8 MHz offset (100 kHz RBW) 83 dB at 6 MHz offset (100 kHz RBW)
Burst count	1000 maximum
Carrier power range	–5 dBm to +30 dBm
Dynamic range for GMSK modulation (typical)	75 dB at 400 kHz offset (30 kHz RBW) 80 dB at 600 kHz offset (30 kHz RBW) 84 dB at 1.2 MHz offset (30 kHz RBW) 88 dB at 1.8 MHz offset (30 kHz RBW)
Dynamic range for 8-PSK modulation (typical)	75 dB at 400 kHz offset (30 kHz RBW) 80 dB at 600 kHz offset (30 kHz RBW) 84 dB at 1.2 MHz offset (30 kHz RBW) 88 dB at 1.8 MHz offset (30 kHz RBW)
Burst count	1000 maximum

Opt. 25 – cdma2000 1xSignal Analysis Software

Perform key measurements for cdma2000 forward link (3GPP2 C.S0010) and reverse link (3GPP2 C.S0011).

cdma2000 1x Forward Link

Characteristics	Description
ACPR
CCDF
Intermodulation distortion
Occupied bandwidth
Spectrum emission mask
Code domain power
QPSK EVM
Modulation Accuracy (composite)
Channel power
Minimum power at RF input	–50 dBm
Absolute power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.6 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz, Signal power: 0 dBm to –50 dBm after auto level is performed at 10 MHz span.
Relative power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.2 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz, Signal power: 0 dBm to –30 dBm after auto level is performed at 10 MHz span, 0 dBm input.
Resolution	0.01 dB
Minimum carrier power at RF input	–40 dBm
Dynamic range 765 kHz offset 1.995 MHz offset 3.125 MHz offset 4 MHz offset	At –5 dBm signal input 76 dB (30 kHz BW) 81 dB (30 kHz BW) 81 dB (30 kHz BW) 82 dB (30 kHz BW)
Histogram resolution	0.01 dB
Measurement filter	Rectangular, Root Nyquist, Nyquist, and Gaussian
Minimum carrier power at RF input	–50 dBm
Measurement accuracy	0.2%
Minimum carrier power at RF input	–5 dBm
Dynamic range 1.995 MHz offset	82 dB (30 kHz BW)
Relative code domain power accuracy	±0.15 dB/±0.075 dB (typical)
Minimum carrier power at RF input	–40 dBm
EVM floor, typical	2.0%
Minimum carrier power at RF input	–40 dBm
Composite EVM floor, typical	2.0%
Rho (ρ)	0.999
Frequency error accuracy	±10 Hz + center frequency accuracy
Timing accuracy (tau)	±250 ns

cdma2000 1x Reverse Link

Characteristics	Description
Channel power
ACPR
CCDF
Occupied bandwidth
Spectrum emission mask
Code domain power
QPSK EVM
Modulation Accuracy (composite)
Minimum power at RF input	–50 dBm
Absolute power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.6 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to –50 dBm after auto level is performed at 10 MHz span.
Relative power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.2 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to -30 dBm after auto level is performed at 10 MHz span, 0 dBm input.
Resolution	0.01 dB
Minimum carrier power at RF input	–40 dBm
Dynamic range 900 kHz offset 1.995 MHz offset 3.125 MHz offset 4 MHz offset	At –5 dBm signal input 76 dB (30 kHz BW) 81 dB (30 kHz BW) 81 dB (30 kHz BW) 82 dB (30 kHz BW)
Histogram resolution	0.01 dB
Intermodulation distortion
Measurement filter	Rectangular, Root Nyquist, Nyquist, and Gaussian
Minimum carrier power at RF input	–50 dBm
Measurement accuracy	0.2%
Minimum carrier power at RF input	–5 dBm
Dynamic range 1.995 MHz offset	82 dB (30 kHz BW)
Relative code domain power accuracy	±0.15 dB/±0.075 dB (typical)
Minimum carrier power at RF input	–40 dBm
EVM floor, typical	2.0%
Minimum carrier power at RF input	–40 dBm
Composite EVM floor, typical	2.0%
Rho (ρ)	0.999
Frequency error accuracy	±10 Hz + center frequency accuracy

Opt. 26 – 1xEV-DO Signal Analysis Software

Perform key measurements for 1xEV-DO forward link (3GPP2 C.S0032) and reverse link (3GPP2 C.S0033).

1xEV-DO Forward Link

Characteristics	Description
Channel power
CCDF
Intermodulation distortion
Occupied bandwidth
ACPR
Spectrum emission mask
QPSK EVM
Modulation Accuracy (composite)
Minimum power at RF input	–50 dBm
Absolute power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.6 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to –50 dBm after auto level is performed at 10 MHz span.
Relative power measurement accuracy (at 20 °C to 30 °C, excluding mismatch error), typical	±0.2 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to -30 dBm after auto level is performed at 10 MHz span, 0 dBm input.
Resolution	0.01 dB
Histogram resolution	0.01 dB
Measurement filter	Rectangular, Root Nyquist, Nyquist, and Gaussian
Minimum carrier power at RF input	–50 dBm
Measurement accuracy	0.2%
Minimum carrier power at RF input	–40 dBm
Dynamic range 765 kHz offset 1.995 MHz offset 3.125 MHz offset 4 MHz offset	At –5 dBm signal input 76 dB (30 kHz BW) 81 dB (30 kHz BW) 81 dB (30 kHz BW) 82 dB (30 kHz BW)
Minimum carrier power at RF input	–5 dBm
Dynamic range 1.995 MHz offset	82 dB (30 kHz BW)
Code domain power
Relative code domain power accuracy	±0.15 dB/±0.075 dB (typical)
Minimum carrier power at RF input	–40 dBm
EVM floor, typical	2.0%
Minimum carrier power at RF input	–40 dBm
Composite EVM floor, typical	2.0%
Rho (ρ)	0.999
Frequency error accuracy	±10 Hz + center frequency accuracy
Timing accuracy (tau)	±250 ns

1xEV-DO Reverse Link

Characteristics	Description
Channel power
CCDF
Intermodulation distortion
Occupied bandwidth
Spectrum emission mask
Code domain power
Modulation Accuracy (composite)
Minimum power at RF input	–50 dBm
Absolute power measurement accuracy (at 20 to 30 °C, excluding mismatch error), typical	±0.6 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to –50 dBm after auto level is performed at 10 MHz span.
Relative power measurement accuracy (at 20 to 30 °C, excluding mismatch error), typical	±0.2 dB at conditions below: Signal frequency: 824 – 960 MHz or 1750 – 2170 MHz Signal power: 0 dBm to –30 dBm after auto level is performed at 10 MHz span, 0 dBm input.
Resolution	0.01 dB
Histogram resolution	0.01 dB
Measurement filter	Rectangular, Root Nyquist, Nyquist, and Gaussian
Minimum carrier power at RF input	–50 dBm
Measurement accuracy	0.2%
ACPR
Minimum carrier power at RF input	–40 dBm
Dynamic range 765 kHz offset 1.995 MHz offset 3.125 MHz offset 4 MHz offset	At –5 dBm signal input 74 dB (30 kHz BW) 83 dB (30 kHz BW) 83 dB (30 kHz BW) 84 dB (30 kHz BW)
Minimum carrier power at RF input	–5 dBm
Dynamic range 1.995 MHz offset	82 dB (30 kHz BW)
Relative code domain power accuracy	±0.15 dB/±0.075 dB (typical)
QPSK EVM
Minimum carrier power at RF input	–40 dBm
EVM floor, typical	2.0%
Minimum carrier power at RF input	–40 dB
Composite EVM floor, typical	2.0%
Rho (ρ)	0.999
Frequency error accuracy	±10 Hz + center frequency accuracy

Opt. 27 – 3GPP Release 5 Downlink (HSDPA) Analysis Software

Perform key measurements for 3GPP TS25.141 v5.7.0

3GPP-R5 Downlink

Characteristics	Description
Channel power measurement
ACLR measurement
Modulation Format	QPSK, 16QAM auto detection
Minimum power at RF input	–50 dBm
Absolute power measurement accuracy (typical)	±0.6 dB at 20 °C to 30 °C, excluding mismatch error Signal frequency: 1900 – 2200 MHz Signal power: +10 dBm to –30 dBm after auto level is performed at 10 MHz span.
Relative Power Measurement Accuracy (typical)	±0.2 dB at 20 °C to 30 °C, excluding mismatch error Signal frequency: 1900 – 2200 MHz Signal power: 0 dBm to –30 dBm after auto level is performed at 10 MHz span.
Resolution	0.01 dB
Minimum carrier power at RF input	–40 dBm
Dynamic range	Test model 1, 16 ch, input power >–5 dBm 60 dB, typically 66 dB (5 MHz offset) 63 dB, typically 70 dB (10 MHz offset)
CCDF measurement
Histogram Resolution	0.01 dB
OBW (Occupied Bandwidth) measurement
Minimum carrier power at RF input	–50 dBm
Measurement accuracy	0.2% (5 MHz Span, 1000 times averaging)
Spectrum emission mask
Dynamic range	82 dB (30 kHz BW, Input Power >–5 dBm, 5 MHz offset)
Code domain power
Relative accuracy of code domain power accuracy	±0.15 dB, typically ±0.075 dB Using Test Model 5, Total Power = 0 dBm, Code Level >–15 dB
QPSK EVM (Pilot Channel Only)
Minimum carrier power at RF input	–60 dBm (EVM <9 %)
EVM floor (typical)	2.0% (Input Power >–40 dBm, 10 times averaged)
Modulation Accuracy (Composite, Test Model 5)
Minimum carrier power at RF input	–60 dBm (EVM < 9%)
Composite EVM floor (typical)	2.5 % (Input Power > –40 dBm, 10 times averaged)
Frequency error accuracy	±10 Hz + (center frequency accuracy)
Modulation accuracy (Composite, Alternate Scrambling Code)
Minimum carrier power at RF input	–60 dBm (EVM <9%)
Composite EVM floor (typical)	2.5% (Input Power >–40 dBm, 10 times averaged)
Frequency error accuracy	±10 Hz + (center frequency accuracy)

3GPP-R5 Uplink

Characteristics	Description
ACK/NACK Analysis
Code domain power
ACK/NACK Analysis Function	ACK/NACK/DTX detection, CQI decode
Relative accuracy of code domain power accuracy	±0.15 dB, typically ±0.075 dB (Total Power = 0 dBm, Code Level >–15 dB )

Opt. 28 – 3GPP Release 4 Downlink and Uplink (TD-SCDMA)

Perform key measurements for TS25.102 (UL), 3GPP TS25.142 (DL)

Characteristics	Description
General
Channel power measurement
ACLR Measurement
CCDF Measurement
Code domain analysis
Modulation and frequency related
Frequency range	1850 – 2050 MHz
Minimum power at RF input	–60 dBm
Absolute power measurement accuracy (typical, after auto-level performed, excluding mismatch error, 5 MHz span)	±0.6 dB (Signal power +10 dBm to –30 dBm, 20 to 30 °C)
Relative power measurement accuracy (typical, after auto-level performed, excluding mismatch error, 5 MHz span)	±0.2 dB (Signal power +0 dBm to –30 dBm, 20 to 30 °C)
Resolution	0.01 dB
Dynamic range	(8 active DPCH, Timeslots 4, 5, 6), input power >–20 dBm 60 dB, 1.6 MHz offset 61 dB, 3.2 MHz offset
Histogram resolution	0.01 dB
Relative code domain power accuracy	Input power > –40 dBm ±0.15 dB (±0.075 typical) at code power >–10 dBc ±0.30 dB (±0.15 typical) at code power >–25 dBc
Code domain residual error	<–40 dB (Input power >–40 dBm)
Modulation format	QPSK
Residual EVM floor	≤1.5%, input level >–40 dBm (1 DPCH in timeslots 4, 5, and 6)
Residual origin offset	≤–40 dB, input level >–40 dBm (1 DPCH in timeslots 4, 5, and 6)
Frequency error accuracy	±10 Hz + (center frequency accuracy)
Frequency lock range	±4 kHz from defined carrier frequency (input level >–40 dBm)
Other measurements	Occupied BW (OBW) Spectrum Emissions Mask (offset from carrier and inband, ungated)

Opt. 29 – IEEE 802.11 a/b/g/n Analysis Software

Characteristics	Description
Residual EVM for IEEE802.11a/g/n 54 Mb/s OFDM (typical)	≤–44 dB at 2.447 GHz center frequency, ≤–42 dB at 5.5 GHz center frequency
Residual EVM for IEEE802.11b 11 Mbps CCK with Raised cosine filter (typical)	≤0.7% at 2.447 GHz center frequency
Residual EVM against Frequency Offset (±10 MHz), OFDM signal conforming to IEEE802.11g, 16.6 MHz BW, 52 sub carriers, 64 QAM, 54 Mb/s, with long training symbol correction (typical)	≤–41 dB, Center Frequency of the Analyzer is 5.0 to 6.0 GHz, Carrier Center is ±10 MHz apart from the Center Frequency setting
Residual EVM for Draft IEEE 802.11n SISO in Green Mode using 16QAM and Long Training Symbol1 (typical)	≤–46 dB at 2.447 GHz center frequency and 20 MHz bandwidth ≤–42 dB at 2.447 GHz center frequency and 40 MHz bandwidth
Residual EVM for Draft IEEE 802.11n MIMO in Green Mode using 16QAM and Long Training Symbol1 (typical)	≤–42 dB at 2.447 GHz center frequency, 20 MHz bandwidth and channel model A ≤–44 dB at 2.447 GHz center frequency, 20 MHz bandwidth and channel model B ≤–42 dB at 2.447 GHz center frequency, 40 MHz bandwidth and channel model A ≤–41 dB at 2.447 GHz center frequency, 40 MHz bandwidth and channel model B

*¹ Measurement performance for RSA3408A only.

IEEE 802.11 Measurements

Measurements	Measurement Contents	802.11a	802.11b	802.11g	802.11n
Power Analysis
Transmission Analysis
Modulation Analysis
EVM vs. Time	EVM	X	X	X	X
	Magnitude Error	X	X	X	X
	Phase Error	X	X	X	X
Power vs. Time	—	X	X	X	X
Constellation	—	X	X	X	X
EVM vs. SC	EVM	X	X	X	X
	Magnitude Error	X	X	X	X
	Phase Error	X	X	X	X
Power vs. SC	—	X	X	X	X
SC Constellation	—	X	X	X	X
Frequency Error	—	X	X	X	X
OFDM Flatness	—	X	—	X	X (SISO only)
OFDM Linearity	—	X	—	X	X (SISO only)
Symbol Table	—	X	X	X	X
2 x 2 MIMO Signal Analysis	—	—	—	—	X
Spectrum Mask	—	X	—	X	X
Transmit Power	—	—	X	X	—
Transfer Function vs. Time	—	—	—	—	X
Delay Profile vs. Time	—	—	—	—	X

Opt. 40 – 3GPP Release 6 (HSUPA) Analysis Software

Perform key measurements for 3GPP TS25.211 v6.7.0, TS25.212 v6.8.0, TS25.213 v6.5.0

3GPP-R6 Uplink

Characteristics	Description
Code domain power
Modulation Accuracy (Configuration 2)
Modulation Format	Channel detection, IQ split analysis
Channel power measurement
Minimum power at RF input	–50 dBm
Relative Power Measurement Accuracy (typical)	±0.2 dB at 20 °C to 30 °C, excluding mismatch error Signal frequency: 1900 – 2200 MHz Signal power: 0 dBm to –30 dBm after auto level is performed at 10 MHz span.
Resolution	0.01 dB
Relative accuracy of code domain power accuracy	±0.15 dB, typically ±0.075 dB Using Configuration 2, Total Power = 0 dBm, Code Level >–15 dB
QPSK EVM (Pilot Channel Only)
Minimum carrier power at RF input	–60 dBm (EVM <9 %)
EVM floor (typical)	2.0% (Input Power >–40 dBm, 10 times averaged)
Minimum carrier power at RF input	–60 dBm (EVM < 9%)
Composite EVM floor (typical)	2.5 % (Input Power > –40 dBm, 10 times averaged)
Frequency error accuracy	±10 Hz + (center frequency accuracy)

3GPP-R6 Uplink and Downlink Analysis

Characteristics	Description
Uplink
Uplink Signaling Analysis
Downlink
Downlink Signaling Analysis
Phase discontinuity	Result of Phase Discontinuity in accordance with 3GPP standard TS25.101(V6.9.0) 6.8.4
Gain Ratio over time	Power ratio % over time
Modulation Accuracy over Time	EVM, Mag error, Phase error, PCDE, Frequency error, Origin offset, Phase discontinuity over time
HS-DPCCH Analysis	ACK/NACK/PRE/POST/DTX detection, CQI decode
E-DPCCH Analysis	RSN/E-TFCI/HAPPY decode
DPCCH	TPC, TFCI decode
Modulation Accuracy over Time	EVM, Mag error, Phase error, PCDE, Frequency error, Origin offset over time
E-RGCH (E - Relative Grant Channel) Analysis	UP/HOLD/DOWN detection
E-HICH (E–Hybrid ARQ Indicator Channel) Analysis	ACK/NACK decode
E-AGCH Analysis	AGV/AGS decode

Ordering Information

RSA3408A

Product Options

Opt. 21 - Advanced Measurement Suite Software.

Opt. 23 - W-CDMA Uplink Analysis Software.

Opt. 24 - GSM/EDGE Analysis Software.

Opt. 25 - cdma2000 1x Analysis Software.

Opt. 26 - 1xEV-DO Analysis Software.

Opt. 27 - 3GPP Release 5 Downlink (HSDPA) Analysis Software.

Opt. 28 - TD-SCDMA Analysis Software.

Opt. 29 - WLAN 802.11 a/b/g/n Analysis Software.

Opt. 40 - 3GPP Release 6 (HSUPA) Analysis Software*³.

*³ Options 23 and 27 are required for 3GPP Release 6 analysis in addition to Opt. 40

Upgrade Options

RSA34UP21 - Advanced Measurement Suite Upgrade (customer-installable).

RSA34UP23 - W-CDMA Uplink Analysis Upgrade (customer-installable).

RSA34UP24 - GSM/EDGE Analysis Upgrade (customer-installable).

RSA34UP25 - cdma2000 1x Analysis Upgrade (customer-installable).

RSA34UP26 - 1xEV-DO Analysis Upgrade (customer-installable).

RSA34UP27 - 3GPP Release 5 Downlink (HSDPA) Analysis Upgrade (customer-installable).

RSA34UP28 - TD-SCDMA Analysis Upgrade (customer-installable).

RSA34UP29 - WLAN 802.11 a/b/g/n Analysis Upgrade (customer-installable).

RSA34UP40 - 3GPP Release 6 (HSUPA) Analysis Software Upgrade (customer-installable)*⁴.

*⁴ Options 23 and 27 are required for 3GPP Release 6 analysis in addition to Opt. 40

RSA3303A, RSA3308A

Product Options

Opt. 21 - Advanced Measurement Suite Software.

Upgrade Options

RSA3UP21 - Advanced Measurement Suite Upgrade (customer-installable).
